Blackmagic Design PYXIS 6K Cinema Box Camera (Leica L)

The Blackmagic PYXIS 6K Leica L takes advantage of the technological advancements in digital filmmaking seen in the Blackmagic Design Cinema Camera 6K. It transforms this camera into a box-style cinema camera, incorporating a lockable Leica L lens mount and customizable side plates. Featuring a full-frame 6K sensor, it captures vivid colors, precise skin tones, and an impressive 13-stop dynamic range over its expanded 36 x 24mm sensor area. Recording options include both Blackmagic RAW and H.265 proxy files, which can be saved to the cloud or streamed directly to your preferred social media platform via Ethernet or mobile 4G/5G connectivity. The PYXIS allows for shooting in various resolutions, including up to 6K Open Gate 3:2 video at 36 fps or 6K Anamorphic 6:5 video at 60 fps, among other selectable options.

Engineered for Unparalleled Personalization!

The Blackmagic PYXIS 6K Leica L is meticulously crafted with precision CNC machining from aerospace-grade aluminum, ensuring a lightweight yet incredibly durable frame. Its versatility knows no bounds as you effortlessly attach it to a variety of camera setups, from cranes to gimbals to drones. With an array of 1/4″ and 3/8″ thread mounts on the top and bottom, along with additional side plates, the Blackmagic PYXIS expands your options for peripherals like handles, microphones, or SSDs.

Expansive Cinema-Grade Digital Film Sensor!

The Blackmagic PYXIS 6K Leica L features a vast full-frame sensor boasting a native resolution of 6048 x 4032, surpassing the Super 35 sensor dimensions by almost threefold. This allows for capturing footage with a shallow depth of field or using anamorphic lenses without any cropping, achieving an authentic cinematic look. With 13 stops of dynamic range and dual native ISO up to 25,600, you can expect impeccable low-noise images in any shooting condition. Plus, achieve frame rates of up to 36 fps at full sensor resolution or 120 fps in windowed mode. Paired with Blackmagic’s renowned color science, this sensor empowers you with professional-grade imaging technology akin to high-end digital cinema cameras.

Unrivaled Frame Flexibility of the Blackmagic PYXIS 6K Leica L

The expansive full-frame sensor of the Blackmagic PYXIS offers flexibility across various film formats and aspect ratios without sacrificing quality. Utilize the full sensor for a distinct open gate 3:2 image, allowing for post-production reframing. Its ample size also enables authentic 6:5 anamorphic shooting without cropping, delivering cinematic widescreen images with enhanced detail and resolution. Additionally, the Super 35-sized window on the sensor allows for swift creation of ‘close-up’ shots that seamlessly integrate with open gate footage.

Unlock the Potential of High Dynamic Range (HDR) Imaging with the Blackmagic PYXIS 6K Leica L

Experience the power of the Blackmagic PYXIS 6K Leica L, boasting an exceptional 13-stop dynamic range that ensures the preservation of intricate details across all lighting conditions. Surpassing conventional video cameras, this remarkable feature allows for precise exposure adjustments in various settings, from cozy indoor environments like cafes to the vibrant glow of outdoor scenes streaming through windows. Moreover, the camera delivers a wider color spectrum compared to standard DCI-P3 color spaces, elevating the richness and depth of your visuals.

Unparalleled Performance in Low-Light Conditions with Dual Gain ISO

Featuring dual native ISO capabilities of up to 25,600, the Blackmagic PYXIS excels in minimizing noise while maintaining the full dynamic range of the sensor. With a primary native ISO of 400 for well-lit scenes and a secondary high base ISO of 3200 for low-light environments, this camera ensures exceptional image quality in any lighting scenario.

Flexibility in Resolutions and Frame Rates

The Blackmagic PYXIS offers versatility in resolutions and frame rates, supporting a wide range from HD to DCI 4K and even 6K. With still capture capabilities of up to 24.6 megapixels, it delivers stunning image quality. Maximize your creative potential with frame rates reaching up to 36 fps at 6048 x 4032 in 3:2 open gate format, or 60 fps at 6048 x 2520 in 2.4:1 aspect ratio, along with 60 fps at 4096 x 2160 in 4K DCI. For higher frame rates, sensor windowing allows shooting at up to 100 fps at 2112 x 1184 in Super 16 format. Additionally, the camera supports true anamorphic 6:5 shooting at significantly higher resolutions, reaching 4.8K at 24 fps with a resolution of 4832 x 4032. Notably, it also offers 120 fps shooting in 1080HD resolution, expanding your creative possibilities even further.

Large 4″ LCD Monitor of Blackmagic PYXIS 6K Leica L

The Blackmagic PYXIS 6K Leica L features a generous 4-inch LCD monitor, delivering high resolution and HDR capabilities, perfect for monitoring and reviewing shots during production. Boasting 1500 nits of brightness, this HDR touchscreen ensures clear visibility, even under bright sunlight. On-screen overlays provide crucial information such as status, record parameters, histograms, levels, and frame guides. Moreover, the display facilitates the quick application of 3D LUTs to achieve desired colors and looks.

All Controls at your Fingertips

Conveniently positioned within easy reach, all essential controls are available on the Blackmagic PYXIS, offering both touchscreen and physical options for functions like ISO, white balance, and shutter speed. A scroll wheel enables swift adjustments to settings, while three customizable function buttons streamline access to frequently used commands. Intuitively placed recording and still buttons, along with function keys for features like high frame rate, focus, zoom, and false color, enhance operational efficiency. Additionally, controls can be locked to prevent inadvertent changes during critical moments or when the camera is inaccessible.

Side Plates for Flexible Mounting Options!

For flexible mounting solutions, the Blackmagic PYXIS includes a standard plate made from aircraft-grade aluminum, featuring two 1/4-inch and one 3/8-inch thread mounts for attaching microphones, brackets, or other accessories. Alternatively, users can utilize the provided SSD plate, offering a secure attachment point for a USB-C drive for recording or a mobile phone for live streaming. For increased versatility, the optional Rosette Plate provides five 1/4-inch and four 3/8-inch thread mounts, along with a rosette mounting point for handgrips or extension arms.

Film with your Blackmagic PYXIS 6K Leica L directly onto CFexpress cards or external disks!

Equipped with dual CFexpress card recorders and a USB-C expansion port, the Blackmagic PYXIS 6k allows for seamless recording onto external flash media disks or SSDs. CFexpress media ensures optimal capture of full-resolution, 12-bit Blackmagic RAW files. Plus, with two CFexpress slots, you can continuously record by swapping out full cards without any interruptions!

Make use of 5G or 4G smartphones to enable mobile data connectivity for your Blackmagic PYXIS 6K Leica L

Transfer files to Blackmagic Cloud effortlessly by connecting an Apple or Android phone via mobile data. Simply link your phone to the USB-C port, and the Blackmagic PYXIS 6k will automatically configure for mobile data usage. It’s compatible with the latest high-speed 5G phones as well as 4G models! Alternatively, you can opt for a wired Ethernet connection via the camera’s Ethernet port. This allows for real-time media transfer during shooting, enabling post-production teams worldwide to begin work immediately!

Easily connect professionally with a variety of video output options!

The Blackmagic PYXIS 6k offers a comprehensive range of connections for audio, monitoring, power, and more. With a 12G-SDI output featuring HDR and Ultra HD support, the camera facilitates on-set monitoring. Connect an SDI display for real-time image monitoring, complete with overlays displaying essential information and camera status. SDI enables longer cable runs compared to HDMI, making it easier to reach monitors positioned farther away on set.

Utilize Built-in Microphones and Professional Audio Inputs with Blackmagic PYXIS 6K Leica L

Equipped with a mini XLR input that provides 48 volts of phantom power, the Blackmagic PYXIS 6K facilitates seamless connection of lapel mics and booms. Its built-in mics, boasting an impressively low noise floor, withstand shock and wind, and excel in capturing high-quality sound, making them ideal for recording guide tracks on location. Additionally, the camera offers a 3.5mm audio input for video camera microphones, a built-in speaker for playback, and a 3.5mm headphone jack. These diverse audio connectivity options empower users to record separate audio tracks using microphones without necessitating an external mixer.

Experience Film Looks by Loading Custom 3D LUTs!

With the Blackmagic PYXIS 6K, users can load custom 3D LUTs to replicate cinematic aesthetics. By applying desired “looks” to the monitor, 3D LUTs offer a solution for previewing how final images will appear during post-production editing. These LUTs can be temporarily applied for monitoring purposes or directly recorded into Blackmagic RAW files for post-production manipulation. Compatible with industry-standard 17 and 33 point 3D LUT files, as well as built-in LUTs like Extended Video, Film to Video, and Film to Rec.2020, this camera offers extensive creative flexibility.

Harness USB-C for External Disks and Ethernet Control

Featuring a USB-C Expansion Port operating at speeds of up to 5 Gb/s, the Blackmagic PYXIS 6K allows users to connect external accessories such as flash drives and high-capacity SSDs for extended recording capabilities. Moreover, the camera integrates a built-in Ethernet port for seamless network control via secure and user-friendly REST APIs. This functionality enables convenient file transfers from the camera over the network, enhancing workflow flexibility and convenience.

Enhanced Built-In SRT and RTMP Live Streaming Feature

Embrace the world of live streaming directly from your film sets! With the Blackmagic PYXIS 6k, you now have access to a built-in hardware streaming engine that seamlessly supports RTMP and SRT streaming to a variety of platforms such as YouTube, Facebook, and more! Connectivity options abound: opt for Ethernet for a stable connection or utilize your 4G or 5G phone to harness mobile data while on the move!

Seamless Wireless Bluetooth Camera Remote Management

When your camera is situated in challenging or inaccessible locations, take command effortlessly with Bluetooth from distances of up to 30 feet away. Whether you favor the Blackmagic Camera Control app on your iPad or third-party apps like Bluetooth+ or tRigger on your iOS and Android devices, complete control is just a tap away. Furthermore, unlock endless potential with a complimentary developer SDK featuring sample code accessible from the Blackmagic Design developer website, enabling you to tailor your own remote camera control and digital slate solutions to suit your needs!

Flexible Power Options with Battery or 12V DC

Effortlessly energize your Blackmagic PYXIS 6k with versatile power solutions, whether it’s utilizing the robust BP-U series batteries or connecting to a 12V DC power source. Experience extended shooting sessions with the highest capacity BP-U series battery, granting over 3 hours of uninterrupted filming on a single charge! For prolonged shoots, maintain seamless power supply by effortlessly linking to DC power through the secure locking connector, ensuring consistent filming flow, especially when your camera is mounted or placed on a jib. Moreover, benefit from the convenience of international socket adapters included in the package for adaptable usage across the globe.
