DJI SDR Transmission Combo
Key Features
- Complete Wireless Video Transmission Kit
- SDR Tri-Bandwidth Technology
- Transmit up to 1080p60 Video
- DFS, 2.4 & 5.8 GHz with Auto Hopping
- Transmit to Tablet/Phone or SDR Receiver
- Wireless SDR Range of up to 1.9 Miles
- Up to 20 Mb/s Bit Rate, 35ms Low Latency
- Broadcast & Control Modes
- HDMI & 3G-SDI Video I/O
- L-Series Battery Plates, USB-C PD Inputs
2,190.00AED VAT Excl.
Available on backorder
DJI SDR Transmission Transmitter
For stable, high-quality video transmission on a small-to-medium-sized shooting set, the DJI SDR is designed for long-range transmission of footage up to 1080p60 resolution using DJI’s proprietary technology. SDR (Software Defined Radio) transmission uses a tri-bandwidth (DFS, 2.4 GHz, and 5.8 GHz) automatic frequency-hopping system, resulting in high penetration and distances up to 1.9 miles. The system is ideal for transmitting footage from a camera rig to an unlimited number of receivers or mobile devices, especially on crowded sets or around dense architecture that would otherwise overwhelm a conventional consumer Wi-Fi-based solution.
Robust Transmission up to 10,000′
High-Quality Image Transmission of DJI SDR
Seamless Auto-Frequency Hopping
SDR technology supports seamless auto-frequency hopping across the 2.4 GHz, 5.8 GHz, and DFS frequency bands. In case of interference, it can automatically switch to the cleanest channel when operating in complex environments with many obstacles.When the SDR Transmission system is connected to the app in SDR Control mode or Wi-Fi mode, users can also manually switch channels within the app and monitor channel quality simultaneously.
DJI SDR Supports Unlimited Number of Receivers
Metadata Transmission
Voice Call through DJI SDR
Camera/Gimbal Control
The SDR Transmission system supports PTP control over cameras, displaying and adjusting aperture, shutter, ISO, and even triggering the camera’s photo-taking and video-recording functions through the app. It also supports CEC control for Sony cameras using Mirror Control mode. See the DJI SDR Transmission Camera Compatibility list for compatible cameras.When connected to a gimbal, it also supports Force Mobile, virtual joystick, and gimbal recentering functions when connected to the gimbal via the app.
Versatile USB-C Port
Camera Source Switching
App Monitoring Tools
Power Options
The transmitter can be powered directly via a USB-C cable using a USB PD fast charger, a standard USB power supply, or via an L-series battery using its built-in port on the back.The transmitter also includes a gimbal adapter mount, and when used with the DJI RS 4 Pro, RS 4, or RS 3 Pro, the transmitter can be mounted on the gimbal and powered directly by it, eliminating the need for a separate battery.
DJI SDR Transmission Receiver
| Weight | 0.5 kg |
|---|---|
| Dimensions | 14 × 12 × 6 cm |
