Panasonic PM-VP4ULVR-W 4MP PTZ CCTV Camera

Panasonic PM-VP4ULVR-W 4MP PTZ Network Camera

The PM-VP4ULVR-W is a high-performance 4MP PTZ (Pan-Tilt-Zoom) Network Camera designed for advanced surveillance applications. This camera features superior image quality, extensive optical zoom, and enhanced night vision capabilities, making it ideal for outdoor security and monitoring in a wide range of environments.

Key Features:

• Image Quality: Equipped with a 1/2.7″ progressive scan CMOS sensor with Back-Side Illumination (BSI) and Near-field Infrared (NIR) technology, this camera captures high-definition images with up to 2560×1440 resolution at 30fps.
• Low Light Performance: The camera performs exceptionally well in low-light conditions, with a minimum illumination of 0.01 lux (color) and 0 lux with infrared (IR) on.
• Optical Zoom: Boasts an impressive 25x optical zoom capability (f=4.8-120mm), allowing the camera to capture distant objects with fine detail. The zoom operation is smooth and fast, switching from wide to tele in approximately 3.6 seconds.
• Wide Dynamic Range (WDR) & 3D Noise Reduction: Ensures clear images in high-contrast lighting situations, and the 3D Digital Noise Reduction (3D DNR) minimizes noise in low-light video streams.
• Smart IR with 160m Range: The infrared (IR) LEDs provide night vision capabilities with an effective distance of up to 160 meters (525 feet), making it suitable for monitoring large areas during the night.
• H.265 Video Compression: The H.265+/H.265/H.264+/H.264 compression standard reduces bandwidth usage while maintaining high image quality, reducing storage and transmission requirements by up to 50%.
• Advanced Intelligence Features: This camera supports smart tracking of humans and vehicles, as well as perimeter protection with smart detection features such as tripwire, intrusion detection, and region monitoring.
• Pan and Tilt Range: Offers a 360° endless pan rotation and a -10° to 90° tilt range. The pan and tilt speeds are configurable up to 200°/s, with a preset speed of 240°/s, providing fast and precise targeting.
• Preset & Cruise: Supports up to 360 presets, 8 cruise paths, and 4 trace paths, enabling automated surveillance of specific areas.
• Weather and Vandal Protection: Designed for harsh environments, the camera is rated IP67 for dust and water protection, IK10 for vandal resistance, and includes 6000V lightning protection. It also features a built-in turbo fan and heater, ensuring operation in temperatures ranging from -40°C to 60°C (-40°F to 140°F).
• Power Options: The camera can be powered via PoE+ (Power over Ethernet) or DC 12V, with a power consumption of up to 23W when fully operational.

Specifications of Panasonic PM-VP4ULVR-W:

• Image Sensor: 1/2.7″ progressive scan CMOS, BSI, NIR+
• Minimum Illumination: Color: 0.01 lux, B/W: 0.002 lux, 0 lux with IR on
• Lens: 4.8-120mm, F1.65~F3.8, 25x optical zoom
• Field of View (FOV): Horizontal: 55°~2.4°, Vertical: 33°~1.4°, Diagonal: 61.5°~2.8°
• DORI Distance:
  • Detection: Up to 2200m (7218 ft)
  • Recognition: Up to 440m (1444 ft)
• Pan Range: 360° endless
• Tilt Range: -10° to 90°
• IR Range: Up to 160m (525 ft)
• Video Resolution: Up to 2560×1440 @ 30fps
• Compression: H.265+/H.265/H.264+/H.264/MJPEG
• Network Interface: 1 RJ45 10M/100M Adaptive Ethernet, PoE+
• Storage: Micro SD slot, up to 256GB
• Audio Interface: 1 audio input, 1 audio output
• Alarm Interface: 1 alarm input, 1 alarm output
• Operating Conditions: -40°C to 60°C, 90% RH
• Dimensions: Ø173mm x 268mm (Ø6.8″ x 10.55″)
• Weight: Approx. 2.1kg (4.63 lb)
• Certifications: CE, IEC62368-1, RoHS

Applications:

Ideal for outdoor installations where continuous monitoring is required, such as parking lots, stadiums, city surveillance, and large commercial properties. The camera’s robust design ensures reliable operation in extreme weather conditions while delivering superior image quality.

Mounting Options:

The camera can be paired with a variety of mounting accessories, including wall, ceiling, pole, and corner mounts for versatile installation.
