Blackmagic DeckLink Mini Recorder HD

Record HD video over SDI or HDMI with the Blackmagic Design DeckLink Mini Recorder HD by Systec International.

This 1-lane PCIe slot playback card with SDI and HDMI inputs is, compatible with 1-, 4-, 8-, and 16-lane PCIe slots, allowing you to capture up to DCI 2K video over SDI, and HD video over HDMI 2.0.

The card is compatible with such software packages as Wirecast, vMix, and OBS. In addition, the card supports hardware-based real-time color space conversion. The card also automatically switches between SD and HD formats, so it’ll handle all common video formats as well as HDR.

Note:

For use on a Mac, a Mac Pro is required with PCI Express slots.

PCIe Compatibility

PCIe 1-lane card, compatible with 1-, 4-, 8-, and 16-lane PCIe slots on Mac, Windows, and Linux (for use on a Mac, a Mac Pro is required with PCI Express slots)

For more information please click here

Supported Software Applications

• Wirecast
• vMix
• OBS
• Cinergy Capture Pro
• DevTek EasyMediaSuite
• Glookast Capturer
• Livestream Producer
• Metus Ingest
• Softron MovieRecorder
• ToolsOnAir just:in
• Burst Video WebClip2Go & [REC]Marker
• Zoom

Supported Codecs

• AVC-Intra
• AVCHD
• Canon XF MPEG2
• Digital SLR
• DV-NTSC
• DV-PAL
• DVCPRO50
• DVCPROHD
• DPX
• HDV
• HEVC
• XDCAM EX
• XDCAM HD
• XDCAMHD422
• DNxHR & DNxHD
• AppleProRes 4444
• Apple ProRes 422 HQ
• Apple ProRes 422
• Apple ProRes 422LT
• Apple ProRes 422 Proxy
• Uncompressed 8-bit 4:2:2
• Uncompressed 10-bit 4:2:2
• Uncompressed 10-bit 4:4:4

Hardware Frame Buffer

v210 (10-bit YUV), 2vuy (8-bit YUV), ARGB, BGRA (8-bit RGB), r210 (10-bit RGB), R12B, R12L (12-bit RGB)
