Blackmagic Design Mini Converter Optical Fiber 12GSDI
SKU: CONVMOF12G
Key Features
- Converts 12G/6G/3G-SDI to Optical Fiber
- Supports Signals up to DCI 4K25
- Multi-Rate, Bidirectional Capability
- Requires Separate SFP Optical Module
- Automatic Input Signal Detection
- 16-Channel Embedded Audio Support
- Diagrammed Function Switches
- Update via Converter Utility Software
- Locking, Universal Power Supply
- Compact Metal Housing
- 681.00 AED
- 681.00 AED
- Unit price
- per
Dimensions: 15 x 12 x 7 cm
Weight: 1 kg
Description
xThe Blackmagic Design Mini Converter Optical Fiber 12G-SDI is a compact broadcast converter designed for reliable 12G-SDI to optical fiber transmission over long distances. Supporting resolutions up to DCI 4K (25 fps) and UHD 4K (60 fps), it enables high-quality video transport for broadcast studios, live production, sports venues, and professional AV installations.
Featuring bidirectional multi-rate conversion, the converter independently handles SDI-to-fiber and fiber-to-SDI signals, making it ideal for flexible broadcast workflows. It supports 12G, 6G, 3G, HD, and SD-SDI formats with automatic signal detection and carries up to 16 channels of embedded audio.
The integrated SFP slot allows compatibility with a wide range of optical fiber modules (sold separately), while the rugged metal enclosure and locking power connector ensure dependable operation in both studio and field environments. Configuration is simple using the built-in function switches or the Blackmagic Converter Utility for Windows and macOS.
Whether you're extending SDI signals across large facilities or connecting remote production equipment, the Blackmagic Design Mini Converter Optical Fiber 12G-SDI delivers dependable, broadcast-quality fiber conversion.
Explore our complete range of Blackmagic Design Converters and Blackmagic Design products for professional broadcast and video production solutions.
FAQs
What does the Blackmagic Design Mini Converter Optical Fiber 12G-SDI do?
It converts 12G-SDI video to optical fiber and optical fiber back to SDI, allowing long-distance, high-quality video transmission.
Does it support 4K video?
Yes. It supports DCI 4K up to 25 fps and UHD 4K up to 60 fps, along with HD and SD formats.
Is an SFP module included?
No. An SFP optical module is required and is sold separately.
Does it support embedded audio?
Yes. The converter supports up to 16 channels of embedded SDI audio.
Where can I buy the Blackmagic Design Mini Converter Optical Fiber 12G-SDI in the UAE?
You can purchase genuine Blackmagic Design Mini Converter Optical Fiber 12G-SDI products from Systec International, an authorized supplier of professional broadcast and AV equipment in the UAE.
Specs
x| Specification | Details |
|---|---|
| Brand | Blackmagic Design |
| Model | CONVMOF |
| Video Input | 1 × BNC (12G-SDI) |
| Video Output | 1 × BNC (12G-SDI) |
| Expansion Slot | 1 × SFP Slot |
| Input Video Format |
SDI (4:4:4 / 4:2:2 RGB, YUV) DCI 4K: 23.98 / 24 / 25 fps UHD 4K: 23.98 / 24 / 25 / 29.97 / 30 / 50 / 59.94 / 60 fps DCI 2K: 23.98 / 24 / 25 fps DCI 2K PsF: 23.98 / 24 / 25 fps 1080p: 23.98 / 24 / 25 / 29.97 / 30 / 50 / 59.94 / 60 fps 1080 PsF: 23.98 / 24 / 25 / 29.97 / 30 fps 1080i: 50 / 59.94 / 60 fps |
| Output Video Format |
SDI (10-Bit 4:4:4 / 4:2:2 RGB, YUV) DCI 4K: 23.98 / 24 / 25 fps UHD 4K: 23.98 / 24 / 25 / 29.97 / 30 / 50 / 59.94 / 60 fps DCI 2K: 23.98 / 24 / 25 fps DCI 2K PsF: 23.98 / 24 / 25 fps 1080p: 23.98 / 24 / 25 / 29.97 / 30 / 50 / 59.94 / 60 fps 1080 PsF: 23.98 / 24 / 25 / 29.97 / 30 fps 1080i: 50 / 59.94 / 60 fps |
| Embedded Audio |
Fiber Input: 16-Channel Fiber Output: 16-Channel |
| Video Standard Compliance |
SMPTE 259M, 292M, 296M, 297M, 424M-B, 425M, ST-2081 ITU-R BT.601 |
| HDCP Support | No |
| HDR Support | Not Specified by Manufacturer |
| OS Compatibility |
Windows 10 (64-bit Only) macOS 10.15 to 11.1 |
| Power Input | 1 × Barrel (6 to 36 VDC) |
| Power Consumption | 2 W |
| Operating Temperature | 32 to 104°F (0 to 40°C) |
| Storage Temperature | -4 to 113°F (-20 to 45°C) |
| Operating Humidity | 0% to 90% |
