Canon EOS C80 6K Full-Frame Cinema Camera (Canon RF)
SKU: 6389C002
Key Features
- 6K FF Back-Illuminated CMOS Sensor
- 6K30, DCI 4K/2K, UHD 4K120 S35 Recording
- Full Frame and Super35 Modes
- 12G-SDI and HDMI Simultaneous Output
- Triple-Base ISO: 800, 3200, 12,800
- Cinema Raw Light LT, HEVC, AVC Codecs
- 16+ Stops of Total Dynamic Range
- Dual-Pixel CMOS AF II, Built-In NDs
- 1 x BNC Timecode, 2 x Mini-XLR Audio In
- 2 x SD Card Slots, LUT/Long GOP Support
- 17,799.00 AED
- 17,799.00 AED
- Unit price
- per
Description
xThe Canon EOS C80 6K Full-Frame Cinema Camera combines a powerful full-frame back-illuminated stacked CMOS sensor, Canon RF mount, advanced autofocus, and professional connectivity in a compact cinema camera. Designed for filmmakers, content creators, production teams, and broadcasters, the EOS C80 delivers high-quality cinematic footage with flexible recording formats and professional workflow features.
Featuring approximately 19.05MP effective resolution, the EOS C80 supports internal 6K Cinema RAW Light recording and offers XF-AVC S and XF-HEVC S recording options. Its full-frame sensor provides up to 16 stops of dynamic range, helping retain detail in both highlights and shadows.
The camera features triple-base ISO settings of 800, 3200, and 12,800, making it suitable for a wide range of lighting conditions. Dual Pixel CMOS AF II provides advanced autofocus performance, while the built-in mechanical ND filter system offers multiple levels of light reduction for greater exposure control.
For professional production workflows, the Canon EOS C80 includes 12G-SDI and HDMI outputs, dual Mini-XLR audio inputs, a 3.5mm microphone input, headphone output, USB-C, Ethernet, and BNC timecode connectivity. Dual SD card slots provide flexible media storage, while the 3.5-inch touchscreen LCD makes camera operation and monitoring convenient.
With support for 6K RAW recording, 4K recording at up to 120 fps, full-frame and Super 35 modes, advanced autofocus, built-in ND filters, and professional audio and video connectivity, the Canon EOS C80 is an excellent choice for cinema production, documentaries, commercials, corporate videos, live events, broadcast applications, and high-end content creation.
For other professional cinema camera options browse the Canon camera collection. You can also pair the EOS C80 with compatible Canon RF lenses for different shooting requirements.
In the Box
x- Canon EOS C80 6K Full-Frame Cinema Camera (Canon RF)
- Canon BP-A30N Battery Pack
- Handle Unit
- Canon CA-CP300B Compact Power Adapter
- Canon Single Battery Charger for EOS C300 Mark II, C200, and C200B Batteries
- Microphone Holder
- SS-1200 Shoulder Strap
- Tape Measure Hook
- Grip Belt
- Limited 1-Year Manufacturer Warranty
Specs
xKey Specs
| Lens Mount | Canon RF |
|---|---|
| Image Sensor | Full-Frame |
| Effective Sensor Resolution | 19.05 Megapixel (6008 x 3170) |
| Image Stabilization | Digital |
| ISO/Gain Sensitivity | Native: 100 to 102,400 |
| Max Recording Modes |
Cinema RAW Light 12-Bit Up to 6K at 23.98/24.00/25/29.97 fps XF-AVC S Intra 4:2:2 8/10-Bit Up to DCI 4K at 50/59.94/120 fps XF-AVC S Long GOP 4:2:0 8-Bit Up to DCI 4K at 50/59.94/120 fps XF-HEVC S Long GOP 4:2:2 10-Bit Up to DCI 4K at 50/59.94/120 fps XF-HEVC S Long GOP 4:2:0 10-Bit Up to DCI 4K at 50/59.94/120 fps XF-HEVC S Intra 4:2:0 8-Bit Up to DCI 2K at 23.98/24.00/25/29.97/50/59.94 fps XF-HEVC S Long GOP 4:2:0 10-Bit Up to DCI 2K at 23.98/24.00/25/29.97/50/59.94/60.00 fps XF-HEVC S Long GOP 4:2:0 8-Bit 720p at 23.98/24.00/25/50/59.94 fps |
| Max Video Output | Via HDMI / SDI/BNC / USB: DCI 4K |
| Media/Memory Card Slot | Dual Slot: SD/SDHC/SDXC |
| Mobile App Compatible | Yes: iOS Only; Adjust Settings, Remote Control, View Live Feed |
| Battery | Canon BP-AN Series |
Imaging
| Lens Mount | Canon RF |
|---|---|
| Lens Communication | Yes: Cooke /i |
| Image Sensor | Full-Frame BSI Stacked CMOS |
| Sensor Resolution | Effective: 19.05 Megapixel (6008 x 3170) Actual: 26.67 Megapixel (6202 x 4300) |
| Image Stabilization | Digital, 5-Axis |
| Built-In ND Filter | Mechanical Filter Wheel with 2-Stop (1/4), 4-Stop (1/16), 6-Stop (1/64), 8-Stop (1/256), and 10-Stop (1/1024) ND Filters |
| Internal Filter Holder | No |
| Capture Type | Stills & Video |
Exposure Control
| Shutter Type | Electronic Rolling Shutter |
|---|---|
| Shutter Speed | 1/2000 to 1 Second |
| Shutter Angle | 11.25 to 360° |
| ISO/Gain Sensitivity | Native: 100 to 102,400 |
| Advertised Dynamic Range | 16 Stops |
| White Balance | Range: 2000 to 15,000K; Presets: AWB, Daylight, Set A, Set B, Tungsten |
Focus
| Focus Mode | Continuous-Servo AF, Focus Lock AF Area Mode, Manual Focus, One-Shot AF |
|---|
Video Capture
| Internal Recording |
Cinema RAW Light 12-Bit 6000 x 3164 at 23.98/24.00/25/29.97 fps (553 to 639 Mb/s) 4368 x 2304 at 23.98/24.00/25/29.97/50/59.94 fps (293 to 678 Mb/s) XF-AVC S Intra 4:2:2 8/10-Bit 4096 x 2160 at 50/59.94/120 fps (150 to 600 Mb/s) 3840 x 2160 at 23.98/24.00/25/29.97/50/59.94/120 fps (150 to 500 Mb/s) 2048 x 1080 at 23.98/24.00/25/29.97/50/59.94/120/180 fps (35 to 300 Mb/s) 1920 x 1080 at 23.98/24.00/25/29.97/50/59.94/120/180 fps (35 to 300 Mb/s) XF-AVC S Long GOP 4:2:0 8-Bit 4096 x 2160 at 50/59.94/120 fps (150 Mb/s) 3840 x 2160 at 23.98/24.00/25/29.97/120 fps (100 Mb/s) 2048 x 1080 at 23.98/24.00/25/29.97/50/59.94/180 fps (35 Mb/s) 1920 x 1080 at 23.98/24.00/25/29.97/50/59.94/180 fps (35 Mb/s) XF-HEVC S Long GOP 4:2:2 10-Bit 4096 x 2160 at 50/59.94/120 fps (225 Mb/s) 3840 x 2160 at 23.98/24.00/25/29.97/120 fps (135 Mb/s) 2048 x 1080 at 23.98/24.00/25/29.97/30.00/50/59.94/180 fps (50 Mb/s) 1920 x 1080 at 23.98/24.00/25/29.97/30.00/50/59.94/180 fps (50 Mb/s) XF-HEVC S Long GOP 4:2:0 10-Bit 4096 x 2160 at 50/59.94/120 fps (150 Mb/s) 3840 x 2160 at 23.98/24.00/25/29.97/120 fps (100 Mb/s) 2048 x 1080 at 23.98/24.00/25/29.97/50/59.94/180 fps (35 Mb/s) 1920 x 1080 at 23.98/24.00/25/29.97/59.94/180 fps (35 Mb/s) XF-HEVC S Intra 4:2:0 8-Bit 2048 x 1080 at 23.98/24.00/25/29.97/50/59.94 fps (9 to 16 Mb/s) 1920 x 1080 at 23.98/24.00/25/29.97/50/59.94/60.00 fps (9 to 16 Mb/s) 1280 x 720 at 23.98/24.00/25/29.97/50/59.94 fps (6 Mb/s) XF-HEVC S Long GOP 4:2:0 10-Bit 2048 x 1080 at 23.98/24.00/25/29.97/50/59.94/60.00 fps (9 to 16 Mb/s) 1920 x 1080 at 23.98/24.00/25/29.97/50/59.94 fps (9 to 16 Mb/s) XF-HEVC S Long GOP 4:2:0 8-Bit 1280 x 720 at 23.98/24.00/25/50/59.94 fps (6 Mb/s) Sensor Crops During Recording |
|---|---|
| Video Output | Via HDMI / SDI/BNC / USB: 4096 x 2160 |
| Fast-/Slow-Motion Support | Yes |
| Gamma Curve | Canon Log 2, Canon Log 3, HDR-HLG, Rec709, Rec2020 |
| Built-In Microphone | Stereo |
| Audio Recording |
Cinema RAW Light: 4-Channel, 24-Bit at 48 kHz via LPCM Audio XF-AVC: 4-Channel, 24-Bit at 48 kHz via LPCM Audio XF-AVC S, XF-HEVC S: 4-Channel, 24-Bit at 48 kHz via LPCM Audio XF-AVC S, XF-HEVC S: 2-Channel, 16-Bit at 48 kHz via AAC Audio |
| IP Streaming | H.264, MPEG2, RTP, RTSP, SRT, UDP; 1920 x 1080 at 50i, 50p, 59.94i, 59.94p (4.0 to 9.0 Mb/s) |
Interface
| Media/Memory Card Slot | Dual Slot: SD/SDHC/SDXC |
|---|---|
| Internal Storage | No |
| Video I/O | 1x BNC (12G-SDI) Output 1x HDMI Output |
| Audio I/O | 2x Mini XLR Input 1x 1/8" / 3.5 mm TRS Stereo Microphone Input on Camera Body 1x 1/8" / 3.5 mm TRS Stereo Headphone Output |
| Power I/O | 1x Barrel (23.7 to 25VDC) Input |
| Other I/O | 1x RJ45 (XC) Control 1x USB-C Monitor 1x BNC (Timecode) (Shared with Video Output) 1x 2.5 mm Sub-Mini (LANC) Control |
| Wireless | Wi-Fi 5 (802.11ac) |
| Mobile App Compatible | Yes: iOS Only App Name: Remote Camera Control App Functionality: Adjust Settings, Remote Control, View Live Feed |
| Global Positioning (GPS, GLONASS, etc.) | No |
Monitor
| Display Type | Primary Monitor: Included External 3.5" Touchscreen LCD |
|---|---|
| Resolution | Primary Monitor: 1280 x 720 |
Power
| Battery | Canon BP-AN Series |
|---|---|
| Power Consumption | ≤19.6 W |
Environmental
| Operating Conditions | 32 to 104°F / 0 to 40°C up to 85% Humidity |
|---|---|
| Storage Conditions | 23 to 113°F / -5 to 45°C up to 60% Humidity |
General
| Shoe Mount | 1x Intelligent Hot Shoe |
|---|---|
| Tripod Mount | 2x 1/4"-20 Female 1x 3/8"-16 Female |
| Netflix Approved | Yes |
| Dimensions (W x H x D) |
6.3 x 5.4 x 4.6" / 160 x 138 x 116 mm 10.9 x 6.8 x 6.3" / 276 x 173 x 160 mm (With Handle, Included Battery, Mic Holder) |
| Weight |
3 lb / 1.30 kg (Body Only) 3 lb / 1.545 kg (With Battery, Handle) |
Packaging Info
| Package Weight | 6.385 lb |
|---|---|
| Box Dimensions (L x W x H) | 11 x 8.9 x 7.4" |
