Roland V-8HD HD Video Switcher
SKU: V-8HD
Key Features
- 8 x HDMI Inputs, 3 x HDMI Outputs
- Up to 1080p60 Resolution Support
- Multi-Format, HDCP Support
- 8-Bit, 4:2:2 Video Processing
- Mix-Effects Bus, 4.3" TFT LCD Screen
- 18-Channel Digital Audio Mixer with FX
- RCA Audio Input, Headphone Output
- Start/Stop Atomos Recorders
- iPad Remote Control App Support
- 7,495.00 AED
- 7,495.00 AED
- Unit price
- per
Dimensions: 16 x 11.5 x 7.3"
Weight: 3.48 kg / 7.67 lb
Description
xThe Roland V-8HD HDMI Video Switcher is a professional live video switcher designed for live events, streaming, presentations, conferences, education, and multi-camera production. It gives production teams an easy way to manage multiple HDMI video sources from one compact and reliable system.
With 8 HDMI inputs and support for video formats up to 1080p60, the V-8HD can connect cameras, computers, media players, and other HDMI sources. It also provides 3 HDMI outputs, including loop and preview outputs, along with HDMI multiview for monitoring your production.
The V-8HD also combines video switching with an 18-channel digital audio mixer, allowing users to manage both video and audio within the same workflow. It supports features such as chroma key, luma key, transitions, graphics, HDCP, and embedded HDMI audio, making it suitable for a wide range of professional production setups.
Its compact design and flexible connectivity make the Roland V-8HD a practical choice for corporate events, conferences, live streaming, houses of worship, education, and other multi-camera workflows. The switcher can also be controlled remotely using a compatible iPad application.
Looking for more professional video production equipment? Explore our Roland products and video switchers to find more solutions for live production and broadcast workflows.
Frequently Asked Questions
How many HDMI inputs does the Roland V-8HD have?
The Roland V-8HD has 8 HDMI video inputs for connecting cameras, computers, media players, and other HDMI sources.
What resolution does the Roland V-8HD support?
The V-8HD supports video formats up to 1080p60, along with several other HD and SD input formats.
Does the Roland V-8HD support audio mixing?
Yes. The V-8HD includes an 18-channel digital audio mixer with effects, as well as analog and embedded HDMI audio support.
Can the Roland V-8HD be used for live streaming?
Yes. Its multiple HDMI inputs, flexible switching, audio mixing, and multiview capabilities make it suitable for live streaming and multi-camera production.
Where can I buy the Roland V-8HD in the UAE?
The Roland V-8HD is available from Systec International in the UAE.
In the Box
x- Roland V-8HD HDMI Video Switcher
- Power Supply
- Limited 3-Year Manufacturer Warranty
Specs
x| Brand | Roland |
|---|---|
| Available M/E Layers | 5 M/E |
| Effect Types | 8x Graphic, Transition, Chroma Key, Alpha Key, Luma Key |
| Downstream Keys | 2x Chroma, Luma |
| Generators | 1x Pattern |
| Audio Mixing | 18-Channel Mixing |
| Switching Type | Pushbutton |
| Processing Resolution | 1080p at 29.97/50/59.94 |
| Color Processing | 8-Bit 4:2:2 YCbCr |
| Audio Processing | 48 kHz / 24-Bit |
| Number of Video Input Sources | 8 |
| Video Inputs | 8x HDMI Female |
| Input Video Format | HDMI (8-Bit 4:2:2 YCC) |
| Input Video Formats | 1080p at 23.98/24/29.97/30/50/59.94/60 fps; 1080i at 50/59.94 fps; 720p at 50/59.94 fps; 576p at 50 fps; 576i / 625 lines at 50 fps; 480p at 59.94 fps; 480i / 525 lines at 59.94 fps; WUXGA (1920 x 1200) at 60 fps |
| Audio Inputs | 1x 2RCA Stereo Analog Female |
| Input Audio Format | Analog: 48 kHz / 24-Bit |
| Embedded Audio Input | HDMI: 2-Channel (per Input) |
| Video Output Channels | 3 |
| Video Outputs | 2x HDMI Female (Loop Output), 1x HDMI Female (Preview) |
| Output Video Format | HDMI (8-Bit 4:2:2 YCC) |
| Output Video Formats | 1080p at 50/59.94 fps; 1080i at 50/59.94 fps |
| Audio Outputs | 1x 1/4" TRS Stereo Analog Female |
| Output Audio Format | Analog: 48 kHz / 24-Bit |
| Embedded Audio Output | HDMI: 2-Channel (per Output) |
| Multiview Output | 1-Way Multiview via HDMI |
| Monitor Output | 1x HDMI |
| Other I/O | 1x USB-A Firmware Input, 1x USB-B Control Input |
| HDCP Support | Yes |
| Display Size | 4.3" |
| Screen Resolution | 480 x 272 |
| Processor | Not Specified by Manufacturer |
| Wireless | No |
| Power I/O | 1x Barrel (12 to 17 VDC) Input |
| Power Consumption | Device: 3.3 A / 39.6 W |
| Operating Conditions | 32 to 104°F / 0 to 40°C |
| Dimensions | 12.48 x 7.6 x 2.76" / 317 x 193 x 70 mm |
| Weight | 4.41 lb / 2 kg |
| Package Weight | 7.67 lb |
| Box Dimensions (L x W x H) | 16 x 11.5 x 7.3" |
